Operation Techniques 89
Table 4-5 Setpoint Actions
Action type Action target
Description Range
No action n/a 0
Set user event flag Flag number #1 - #8
Reset user event flag Flag number #1 - #8
Operate relay Relay number #1 - #4
Increment counter Counter number #1 - #8
Decrement counter Counter number #1 - #8
Clear counter Counter number #1 - #8
Reset energy registers n/a 0
Reset extreme demands n/a 0
Reset TOU energy n/a 0
Reset TOU demands n/a 0
Clear counters n/a 0
Clear Min/Max registers n/a 0
Event logging Setpoint transition
mode - type of events
that trigger logging
0 = setpoint operation
1 = setpoint release
2 = either transition
Data logging Log number #1-#16
High-speed (32/16)
waveform logging
n/a 0
High-resolution (128/4)
waveform logging
n/a 0
All actions are always run in the order they are enumerated in the setpoint
specification.
Each action can be run by either setpoint, and can be repeated up to four times
within each setpoint. The exception concerns to the logging actions directed to the
same target. Event logging on setpoint operation will be made once per setpoint,
disregarding of the number of actions specified. Data logging and waveform logging
directed to the same memory partition will be made once for the first setpoint among
those that specify the same action.
All actions, except operating relay, are run immediately with operating a setpoint.
Relay output operation is the only action that allowed to be shared by multiple
