SATEL-EASy+
User guide
Version 1.33
45
Radio Compatibility *)
Defines the radio protocol.
Options are SATELLINE-3AS, SATELLINE-3AS NMS, SATELLINE-
3AS-OA, SATEL-8FSK-1, SATEL-8FSK-2, SATEL-16FSK-1,
SATELLINE-2ASxE, PacCrest-4FSK, PacCrest-GMSK
TrimTalk450s (P), TrimTalk450s (T), PacCrest-FST, SOUTH, RTCM
SC135 1 25kHz FEC On, RTCM SC135 2 12.5kHz FEC On, RTCM
SC135 3 25kHz FEC Off, RTCM SC135 4 12.5kHz FEC Off.
Default value: SATELLINE-3AS
Call Sign
Call sign means that the modem transmits its Call sign ID
periodically using Morse keying.
Call sign is configured using three settings:
a) Call sign mode sets Call sign operation ON/OFF.
b) Call sign ID defines Morse code to be transmitted, max. sixteen
characters, capital letters and numbers are allowed (lower case
letters are converted automatically to uppercase letters).
If Call sign mode is not used (OFF) you can enter e.g. "CALLSIGN"
for the Call sign ID.
c) Call sign timer is the interval (1...30 min) between Call sign
transmissions.
One Call sign transmission may take several seconds to transmit,
depending on the Call sign ID.
Default value: Call sign mode OFF
RX Address
See the chapter REPEATER MODE AND ADDRESSING
Default value: OFF (Rx Address Disabled)
TX Address
See the chapter REPEATER MODE AND ADDRESSING
Default value: OFF (Tx Address Disabled)
RX addressing to RS port
See the chapter REPEATER MODE AND ADDRESSING
Default value: OFF
TX address auto switch
See the chapter REPEATER MODE AND ADDRESSING
Serial port 1 Status
Defines Port 1 status
Options are: OFF / Diagnostics (NMS)/Data
Default value: Data
Serial port 1 Interface
RS-232 (fixed)
Serial port 1 Data speed
1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200 bps
Default value: 115200 bps
Serial port 1 Data bits
7 Note**), 8 bits
Default value: 8 bits
Serial port 1 Parity bit
None, Even, Odd
Default value: None
Serial port 1 Stop bits
1 or 2
Default value: 1
Serial port 2 Status
Defines Port 2 status
Options are: OFF / Diagnostics (NMS)/Data
