SATEL-EASy+
User guide
Version 1.33
46
Default value: Diagnostics
Available selection is: RS-232/422/485
Default value: RS-232
1200, 2400, 4800, 9600, 19200, 38400 57600, 115200 bps
Default value: 115200 bps
None, Even, Odd
Default value: None
Defines how CTS line acts, the choices are: Clear to send and TX
buffer state.
Default value: Clear to send
Defines how CD line acts, the choices are: RSSI-threshold, Data
on channel, Always ON and Ext Antenna Control.
Default value: RSSI- threshold
Defines how RTS line acts, the choices are: Ignored, Flow Control,
Reception Control
Default value: Ignored
The radio modem recognizes pauses on the serial line and uses
them as criteria for ending the transmission and finding SL
commands. The value range is 3….255 bytes.
In case the serial port data to be transmitted includes pauses
between the characters inside messages, increasing Pause
length will help in keeping the message in one part over the
radio. In general, the value should be kept as small as possible in
order to maximize the performance of the radio system.
Default value: 5
ON/OFF
FEC (Forward Error Correction) improves the reliability of data
transfer over a noisy radio channel. FEC is recommended in case
the link distances are long or if the radio channel is not clean.
However, FEC ON decreases the data transfer speed by about 30
% (depending on used modulation level).
All radio modems, that are to communicate with each other,
must have the same setting for FEC (ON or OFF).
Note that FEC setting applies only to the SATELLINE-3AS radio
protocol, the other radio compatibility modes have their own
FEC bindings (although some previous or special firmware
versions differ in the way FEC setting is handled - in case of doubt
please contact technical support)
Default value: OFF
