20 User Manual SATEL
Zone Test – the submenu contains functions which allow to test the detectors connected
to the zones (see: “Zone testing” p. 33).
Battery test – available to the installer. Upon starting the function, the control panel will
generate events to inform about the status of batteries of the control panel and
hardwired expansion modules with power supply. Additionally, the status of 60. TECH.-
BATTERY LOW type zones will be analyzed.
Manual transmission test – generates an event, which starts the procedure of event
transmission to the monitoring station (a code sent with the system identifier).
Monitoring station test (1A, 1B, 2A, 2B) – allows to send a test transmission to the
monitoring station (separate functions for each of the telephone numbers). When
sending the transmission, messages are displayed to inform about the currently
performed operation. The function is useful when starting the reporting or in case of any
reporting trouble.
Messaging test – allows to test the messaging function. Upon starting the function:
1. Enter the number of the telephone (consecutive number on the telephone list).
2. Press the key.
3. Enter the number of voice message.
4. Press the
key. The control panel will call the indicated number and play back the
message.
Answering test – if this function is started, information on the number of rings and going
off-hook is displayed when answering the telephone call.
Proximity card test – allows to check the number of proximity card and establish to whom
it belongs (if the card belongs to a user of the system).
CA-64 PTSA test – allows to test the mimic board.
View masters – available to the administrator. It makes it possible to check in which
objects the master users are created.
Keypad name – allows to check the given keypad name.
File in DLOADX – displays the date and time of writing the data to the control panel by
means of the DLOADX program and the name of file with control panel data.
Panel version – displays information on the control panel firmware version.
STM program version – displays information on the program version of the processor
used to operate the control panel zones and power supply unit.
IP/MAC ETHM-1 – displays in turn the following information related to the Ethernet module
connected to the control panel:
local IP address,
MAC number,
public IP address,
individual identification number for the purpose of communication via the SATEL
server [ID].
Use the and keys to scroll the information. If several Ethernet modules are
connected to the control panel, use the and keys to scroll the list of modules.
Modules versions – allows to check the firmware versions for devices connected to the
control panel communication buses.
Time synchronization – allows to manually start synchronization of the control panel
clock and the time server. It applies to the control panel to which the ETHM-1 / ETHM-1
Plus module is connected. The address of time synchronization server must be
programmed in the control panel.
