SATEL INTEGRA Plus 19
communication with the GUARDX program through Ethernet, using the TCP/IP
protocols (see: description of the ETHM-1 – GUARDX function, available in the
DOWNLOADING submenu). It can be entered as a name or IP address.
Erase service message – allows the user to delete the service message.
Tests – the following functions are available in the submenu:
Partitions – allows to check the status of partitions accessible to the user and operated
from the keypad. The partition status is presented by means of a symbol. The numbers
placed on the glass allow you to identify the partition numbers. By factory default, the
partition status is shown using the following symbols (which can be changed by the
installer):
b - temporary partition blocking,
? - entry delay,
E - exit delay (less than 10 seconds),
e - exit delay (more than 10 seconds),
P - fire alarm,
A - alarm,
p - fire alarm memory,
a - alarm memory,
a - zone is armed,
- violated zones,
- zone is disarmed, zones OK.
Zones – allows to check the status of zones in the partitions accessible to the user and
operated from the keypad. The zone status is presented by means of a symbol. The
numbers placed on the glass allow you to identify the zone numbers. On starting the
function, the status of zones 1-32 is displayed. Use the  and  keys to display the
status of other zones (see also description of the LEDs, p. 7). By factory default, the
zone status is shown using the following symbols (which can be changed by the
installer):
b - zone bypass,
l - trouble “long violation”,
f - trouble “no violation”,
T - tamper alarm,
A - alarm,
- zone tamper,
M - masking,
- zone violation,
t - tamper alarm memory,
m - masking memory,
a - alarm memory,
- zone OK.
Supply voltages – available to the installer. Enables checking of the supply voltage for
individual expansion modules.
Temperatures – allows to check the temperatures measured by ATD-100 wireless
detectors.
Radio devices – allows to check the radio signal level for ABAX system wireless devices
supported by the control panel.
