SATO CL4NX Plus Driver Manual

32
Installing the Printer Driver for Second and Later Products 1.3.5
When using multiple products, you need to install printer drivers for each product.
When Connected via USB or IEEE1284
Power off the product and connect the product to the computer. 1.
Power on the product. 2.
The Plug and Play feature runs and the printer driver is automatically installed.
If necessary, change the printer name. 3.
Note:
You cannot install the printer driver as port and printer names that have already been created. Change the
name(s).
When Connected via LAN, Wireless LAN or RS-232C
Use the same procedure as the first product to install the printer driver.
Double-click PrnInst.exe. 1.
To finish installing the printer driver, follow the same procedure as the first product. 2.
Note:
You cannot install the printer driver as port and printer names that have already been created. Change the
name(s).
When Connected via Bluetooth
Use the same procedure as the first product to install the printer driver.
Pair the product with the computer. 1.
Double-click PrnInst.exe. 2.
To finish installing the printer driver, follow the same procedure as the first product. 3.
Note:
You cannot install the printer driver as port and printer names that have already been created. Change the
name(s).

SATO CL4NX Plus Specifications

General

Display type	LCD
Product color	Black
Built-in display	Yes
Display diagonal	3.5 \
Type	POS printer
Color	No
Print speed	14 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	305 x 305 DPI
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Maximum media length	600 mm
Maximum roll diameter	254 mm
Supported paper width	39.5 - 128 mm
Maximum printing width	128 mm
Printing media thickness	0.06 - 0.268 µm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Wi-Fi	-
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0+HS
Standard interfaces	Bluetooth, Ethernet, RS-232C, Serial, USB 2.0
Serial interface type	RS-232C
USB 2.0 ports quantity	3
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	271 mm
Width	457 mm
Height	321 mm
Weight	15100 g
