SATO CL4NX Plus Driver Manual

74
4. Settings on the [Printer Settings] Tab
Product settings can be configured on [Printing Defaults] and [Printing Preferences]. As the settings
that can be configured are the same on both screens, this section will use [Printing Preferences]
(Printer Settings) tab to describe the settings.
[Help] is available on all screens. Click it to display a description of that screen.
Check Box Behavior
When a green or blue check box is to the right of a setting, they behave in the manner described
below.
Green Check Box
Selected: [Let printer control this option]
"N/A" will be shown for the value of the setting. This setting value is not sent to the product and
the product setting value is used. "N/A" will also be shown for other settings that must be used in
combination with this setting.
Cleared: [Send this parameter to printer]
The setting values are sent to the product.
Blue Check Box
If you register stock in [Stocks] on the [Driver Settings] tab, this check box will be shown on the right
of the following items.
Media settings
[Width]
[Height]
Print settings
[Speed]
[Darkness]
If you select the stock to be used in [Stock] on [Page Setup], you can change the above setting
values all at once. For details, refer to "4.1 Page Setup."
Blue check boxes are always on and cannot be cleared. However, if you select [Let printer control this
option], the green check box is selected for using the setting values on the product.

SATO CL4NX Plus Specifications

General

Display type	LCD
Product color	Black
Built-in display	Yes
Display diagonal	3.5 \
Type	POS printer
Color	No
Print speed	14 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	305 x 305 DPI
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Maximum media length	600 mm
Maximum roll diameter	254 mm
Supported paper width	39.5 - 128 mm
Maximum printing width	128 mm
Printing media thickness	0.06 - 0.268 µm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Wi-Fi	-
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0+HS
Standard interfaces	Bluetooth, Ethernet, RS-232C, Serial, USB 2.0
Serial interface type	RS-232C
USB 2.0 ports quantity	3
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	271 mm
Width	457 mm
Height	321 mm
Weight	15100 g
