SATO CL4NX Plus Driver Manual

86
5. Sharing the Product
You can share a product connected directly to a computer on the network with other computers.
Connecting When Using the Printer Driver with Sharing Settings
The figure below shows how to connect when using the printer driver with sharing settings.
Set one computer (PC-0) as the print server and set other computers (PC-1, PC-2, PC-3 etc.) as
clients. All computers should be connected using LAN connection and the print server and product
should be connected via USB, Bluetooth, RS-232C or IEEE1284.
Procedure to Configure Printer Driver Sharing Settings
To use the printer driver with sharing settings, follow the steps below:
Install the printer driver on the print server and client computers. 1.
Refer to "5.1 Installing the Printer Driver on the Print Server and Client Computers."
Confirm that a label can be output correctly from the product connected to the print server. 2.
Configure the sharing settings on the product connected to the print server. 3.
Refer to "5.2 Configuring Sharing Settings on the Print Server Printer."
Specify the product connected to the print server setup for sharing as the output destination port 4.
for the client printer and turn off bidirectional communication on the client printer.
Refer to "5.3 Configuring Sharing Settings on the Client Printer."
Restrictions
When you use the printer driver with sharing settings, the following restrictions occur because
bidirectional communication is disabled on the client:
 Errors that occur on the product, such as "Paper End" and "Ribbon End", cannot be recognized.
 You cannot use [Get From Printer] and [Send To Printer] under [Configure Printer] on the [Printer
Properties] > [Driver Settings] tab in the printer driver.
 The settings you change on the [Printing Preferences] > [Printer Settings] tab in the printer driver
cannot be sent to the product (when the green check box is not selected).
LAN
LAN
PC-0
PC-1
PC-2 PC-3
RS-232C
IEEE1284
Product
Client
Print server
USB
Bluetooth

SATO CL4NX Plus Specifications

General

Display type	LCD
Product color	Black
Built-in display	Yes
Display diagonal	3.5 \
Type	POS printer
Color	No
Print speed	14 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	305 x 305 DPI
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Maximum media length	600 mm
Maximum roll diameter	254 mm
Supported paper width	39.5 - 128 mm
Maximum printing width	128 mm
Printing media thickness	0.06 - 0.268 µm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Wi-Fi	-
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0+HS
Standard interfaces	Bluetooth, Ethernet, RS-232C, Serial, USB 2.0
Serial interface type	RS-232C
USB 2.0 ports quantity	3
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	271 mm
Width	457 mm
Height	321 mm
Weight	15100 g
