SATO CL4NX Plus Driver Manual

57
Print the barcode. 7.
The print result is shown below. The numbers "12345" specified as the CODE39 barcode font
are printed as a CODE39 barcode.
Note:
 Some characters cannot be used and there are text length restrictions depending on the barcode type set as
the barcode font. Moreover, if the settings are not configured correctly, the text may not be printed as a
barcode. For the data specifications that correspond to the barcode type, refer to "CL4NX Plus Programming
Reference."
 The string is not shown as a barcode on the edit or preview screens in applications.
 If you cannot select registered barcode font in the application, make sure that the barcode font is registered in
the printer driver to be used for printing.
 The font size has nothing to do with the barcode size. Adjust the data so that it fits into the application layout.
 If the converted barcode does not fit onto the page, it will not be printed. Adjust the position of the data on the
application or adjust the barcode font settings so that the barcode fits onto the media.

SATO CL4NX Plus Specifications

General

Display type	LCD
Product color	Black
Built-in display	Yes
Display diagonal	3.5 \
Type	POS printer
Color	No
Print speed	14 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	305 x 305 DPI
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Maximum media length	600 mm
Maximum roll diameter	254 mm
Supported paper width	39.5 - 128 mm
Maximum printing width	128 mm
Printing media thickness	0.06 - 0.268 µm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Wi-Fi	-
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0+HS
Standard interfaces	Bluetooth, Ethernet, RS-232C, Serial, USB 2.0
Serial interface type	RS-232C
USB 2.0 ports quantity	3
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	271 mm
Width	457 mm
Height	321 mm
Weight	15100 g
