SATO CL4NX Plus Driver Manual

72
Printing defaults
Export or import printer driver settings for all users.
[Import]
Load an exported settings file.
 The content of the imported file will be applied to the [Printing Defaults] and [Driver Settings]
tabs for accounts with administrator privileges.
 This feature is not available for accounts that do not have administrator privileges.
[Export]
The settings on the [Printing Defaults] and [Driver Settings] tabs will be saved to a file.
The file extension is ".drx".
Stream logging
This feature is used by SATO Technical Support. Do not select the [Enable] check box.
Note:
 For details on [Printing Preferences] and [Printing Defaults], refer to "2.1 [Printing Defaults] (For All Users) and
[Printing Preferences] (For Individual Users)."
 Of the settings on the [Driver Settings] tab, the settings in [Configure Printer] cannot be imported or exported.

SATO CL4NX Plus Specifications

General

Display type	LCD
Product color	Black
Built-in display	Yes
Display diagonal	3.5 \
Type	POS printer
Color	No
Print speed	14 ips
Print technology	Direct thermal / Thermal transfer
Maximum resolution	305 x 305 DPI
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Maximum media length	600 mm
Maximum roll diameter	254 mm
Supported paper width	39.5 - 128 mm
Maximum printing width	128 mm
Printing media thickness	0.06 - 0.268 µm
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	30 - 90 %
Operating relative humidity (H-H)	30 - 80 %
Wi-Fi	-
USB connector	USB Type-A / USB Type-B
Bluetooth version	3.0+HS
Standard interfaces	Bluetooth, Ethernet, RS-232C, Serial, USB 2.0
Serial interface type	RS-232C
USB 2.0 ports quantity	3
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1

Weight and Dimensions

Depth	271 mm
Width	457 mm
Height	321 mm
Weight	15100 g
