SATO HT200e - Page 68

SECTION 4 ： FREE MODE
SATO HT200e Page 4-5
FIELD SETTING FOR TABLE DATA
Based on the field destination, the setting, in which “11: Table Data” is specified, is described.
Note 1: For the position of rotation, see 1. in Additional Information for Parameter.
Note 2: When lateral direction is enlarged, space between characters will increase.
Digit
Position(s)
Designated item Description
1, 2 Field designation 11: Table Data
3 Font selection 0: X1 (20 x 50 dots)
1: X2 (
8 x 20 dots)
2: X3 (13 x 21 dots)
4: OCR-B (20 x 24 dots)
4, 5, 6 Vertical position 001 to 784 dot (s): Vertical print position
000: Entry only, where print is not required.
7, 8, 9 Horizontal
position
001 to 384 dot (s): Horizontal print position
10 Rotation position
(Note 1)
0: 0° 2: 180°
1: 90° 3: 270°
11 Character pitch
(Note 2)
0 to 9 dot (s)
12
，
13
Character count 01 to 32: Number of characters in the field
14 Vertical
expansion
1 to 4: Magnification of vertical direction to character
15 Horizontal
expansion
1 to 4 :Magnification of horizontal direction to character
Input Check Digits
16 Input check 0: No check
2: Must enter
17 Set of title 0: Not display as a title in printing preset
1: Initially display as a title in printing preset
(For a format, one field set only.)
18 Set of table
number
1: Table 1 data
3: Table 3 data
2: Table 2 data
19 0 insertion 0: No 0 insertion
1: 0 insertion in right-aligned when copy is required.
(i.e. 1 = 001)
20 Preset 0: No entry in printing preset (Not displayed)
1: Entry in printing preset (Displayed)
21 Color of font 0: Black
4: Black-and-white reversal
3: Red
