SECTION 4 ： FREE MODE
SATO HT200e Page 4-7
FIELD SETTING FOR PRICE
Based on the field designation, the setting, in which “20: Price (Standard)” and “21: Price (POP)”
are signified is described.
Note 1: For the position of rotation, see 1. in Additional Information for Parameter.
Note 2: When horizontal direction is enlarged, space between characters will increase.
Digit
position (s)
Designated item Description
1, 2 Field designation 20: Price (Standard)
21: Price (POP)
3 Font selection Regular POP
0: X1 (20×50 dots)
0: POP 1 (28×48 dots)
1: X2 (
8×20 dots) 1: POP 2 (48×68 dots)
2: X3 (13×21 dots)
2: POP 3 (26×56 dots)
5: Price font (16×24 dots)
4, 5, 6 Vertical position 001 to 784 dot (s): Vertical print position
000: Entry only, where print is not required.
7, 8, 9 Horizontal position 001 to 384 dot (s): Horizontal print position
10 Rotation position
(Note 1)
0: 0 degree 2: 180 degree
1: 90 degree 3: 270 degree
11 Character pitch
(Note 2)
0 to 9 dot (s)
12, 13 Character count 01 to 10: Number of characters in the field
Note that currency mark, comma, or decimal point are not
included.
14 Vertical expansion 1 to 4: Magnification of vertical direction to character
Note that POP font ranges from 1 to 3.
15 Horizontal
expansion
1 to 4: Magnification of horizontal direction to character
Note that POP font ranges from 1 to 3.
Input Check Digits
16 Input check
5: Numeric only
6: Numeric in all digits
7: Numeric is accepted, but currency mark, 0, and un-entry
are not allowed.
17 Input method 0: Enter in left-aligned
1: Enter in right-aligned
18 Insertion
0: None
1: Currency mark only
2: Currency mark and decimal point
5: Currency mark and comma
6: Currency mark, comma, and decimal point
7: Comma and decimal point
19 0 insertion 0: No 0 insertion
1: 0 insertion in right-aligned (i.e. 1 = 001)
20 Preset for general /
Euro currency mark
0: No entry, so that general currency mark is not shown.
1: Entry required, so that general currency mark is shown.
8: No entry, so that Euro currency mark is not shown.
9: Entry required, so that Euro currency mark is shown.
21 Reserved 0: Determined
