SECTION 4
：
FREE MODE
Page 4-8 SATO HT200e
FIELD SETTING FOR CALENDAR
Based on the field designation, the setting, in which “30/31: Calendar” is specified, is described.
Note 1: For the position of rotation, see 1. in Additional Information for Parameter.
Note 2: When horizontal direction is enlarged, space between characters will increase.
Note 3: Where the addition for time and date is specified for the identical format, carried-over time will be reflected to
the date.
Note 4: Separator does not involve in time.
Digit
position (s)
Designated
item
Description
1, 2 Field
designation
30: Calendar/Date
31: Calendar/Time
3 Font selection 1: X2 (
8 x 20 dots)
2: X3 ( 13 x 21 dots)
4, 5, 6 Vertical
position
001 to 784 dot (s): Vertical print position
000: Entry only, where print is not required.
7, 8, 9 Horizontal
position
001 to 384: Horizontal print position
10
Rotation position
(Note 1)
0: 0° 2: 180°
1: 90° 3: 270°
11 Character pitch
(Note 2)
0 to 9 dot (s)
12, 13 Character
count
01 to 10: Number of characters in the field
14 Vertical
expansion
1 to 4: Magnification of vertical direction to character
15 Horizontal
expansion
1 to 4: Magnification of horizontal direction to character
Input Check Digits
16 Input check 6: Numeric in all digits
7: Numeric is accepted, but neither 0 nor un-entry is allowed.
17 Addition 0: No addition
1: Addition
Note that date and time should be arranged separately in each
field per format.
18 Selection for
presentation
For Date filed;
For time filed;
19 Separator
(Note 4)
0: None
1:/
2: -
3:
．
20 Preset 0: No entry in printing preset (Not displayed)
1: Entry in printing preset (Displayed)
21 Reserved 0: Determined
1: mmddyy
2: yymmdd
0: ddmmyy
3: ddmmyyyy
4: mmddyyyy
5: yyyymmdd
0: 5:30 23:05 (Addressed in 24-hour system)
1: AM 5:30 PM 11:05 (AM and PM are affixed.)
2: 5:30 AM 11:05 PM (AM and PM are suffixed.)
To Next Page
