SECTION 4 ： FREE MODE
SATO HT200e Page 4-9
FIELD SETTING FOR BAR CODE
Based on the field designation, the setting, in which “70/71: Bar Code” is specified, is described.
Note 1: For the position of rotation, see 1. in Additional Information for Parameter.
Note 2: The rotation position of 90 and 270° is a hidden mode; the guidance will not be displayed.
Note 3: When horizontal direction is enlarged, space between characters will be increase.
Note 4: When CODE 128 is being set, specify “1”.
Digit
position (s)
Designated
item
Description
1, 2 Field designation 70: Human readable information (HRI) is NOT available.
71: HRI is available.
3 Bar code type 0: NW-7 1: CODE 39
2: INT
２ o f5
3: AN13/UPC-A
4: EAN 8
5: UPC
－ E
6: CODE 128 (C set)
7: CODE 12 (B set)
4, 5, 6 Vertical position 001 to 784 dot (s): Vertical print position
000: Entry only, where print is not required.
7, 8, 9 Horizontal
position
001 to 384 dot (s): Horizontal print position
10 Rotation position
(Note 1)
0: 0° 2: 180°
1: 90° (Note 2) 3: 270° (Note 2)
11 Character pitch
(Note 3)
0 to 9 dot (s)
Note that if HRI is available, it means spacing between the
characters in it.
12, 13 Character count 01 to 22: Number of digits in the bar code
EAN
8: 08
EAN 13: 13
UPC-A : 12
UPC-E : 07
Note that Start/Stop is not included for NW-7/CODE 39.
14 Bar ratio 0 = Invalid (EAN, UPC-A, and UPC-E)
1 = 1:2
2 = 1:2.5
3 = 1:3
15 Bar expansion 2 to 4: (Ratio 1: 2.5 will be enlarged only to twofold and
fourfold)
Input Check Digits
16, 17, 18 Bar height 001 to 240 dot (s)
19 Check digit
(Note 4)
0: No C/D
1: C/D creation (Computing
）
2: C/D check (with input data)
3: Price C/D (Only for EAN 13)
20 Preset 0: No entry in printing preset (Not displayed)
1: Entry in printing preset (Displayed)
21 Reserved 0: Determined
