18 4 Technical information
4.4 Deduster setup and commissioning
Type of deduster: PF-Jet 9000
Set up the deduster with a crane at the transport eyelets intended for this.
The included sealing tape must be glued on between the muffler hood and deduster.
Put the muffler hood on the deduster with the scripture Fa. Richters to the front.
Fasten the hood to the deduster with the lateral closures.
Create electrical connections
Open the fan chamber door and check deduster motor rotating direction. (see arrow at
the motor).
Properly connect pipelines to cleaning machine and seal.
4.5 Machine disassembly
Disconnect the cleaning machine from the circuit and clean.
Disassemble the roller tables at the inlet and outlet sides and put them aside.
Disconnect deduster from the machine.
Remove floor fastenings.
4.6 Electrical connections
The electrical supply is created by a fixed connection. The supply is to be protected according to
the Technical data (see page 16) and the circuit diagram (see page 86).
The electrical supply line is produced by connecting the supply cable in the control cabinet. Ob-
serve the right-ward turning field. The supply is to be protected according to the technical data
(see chapter 4.1 Technical data, page 16) and the circuit diagram (see chapter 8.10, page 86).
The place of setup of the deduster must be selected to
warrant proper stance on firm underground.
When setting up, observe the extraction connection.
