Schwarz SB10B - 8.3 General mechanical spare and wear parts

64 8 Spare parts and circuit diagrams
8.3 general mechanical spare and wear parts
When placing the order, please indicate item number and machine number.
Schwarz GmbH
Engineering
Freiburgerstr. 3b
79822 Titisee-Neustadt
Phone : 0049 7651/5770
Fax: 0049 7651/3770
Email: mail@schalungsreiniger.de
Homepage: www.schalungsreiniger.de
Table 8.2 Total list mechanical spare and wear parts
Preview
Component num-
ber
Description
Features
Item no.011 101
Deep-groove ball bearing
Outer diameter = Ø32
Inner diameter = Ø12
Item no.011 109
Deep-groove ball bearing
Outer diameter = Ø52
Inner diameter = Ø25
Item no.011 202
Deep groove ball thrust
bearingAxial-Rillenkugellager
Outer diameter = Ø42
Inner diameter = Ø25
Width adjustment, among
others
Item no.014 080
Roller carriage screw
M12x160
???
Item no.014 081
Roller carriage axis
Ø12x110
???
Item no.014 226
Safety ring for run-in stop
Plastic black
Stop bolt
Item no.021 129
Safety disc
670x1090x4
Doors, sides
