5.2 Switching on and starting the machine 21
5.2 Switching on and starting the machine
Switching on:
 The machine is switched on via the main switch at the control cabinet on the right side.
To switch the machine on, turn the main switch to the 1-ON position.
 Push the blue EMERGENCY OFF reset button at the control cabinet
 Switch on the control via the green CONTROL ON button.
Starting automatic:
 Tap the automatic mode symbol in the operating panel so that its background turns
green.
 Tap and hold the On button (icon no.: 6, page 20) (for approx. 2.5 s), automatic mode is
activated after an acoustic warning.
5.3 Working with the machine
Safety:
Preparations for automatic mode:
Work process in automatic mode:
 Switch on the machine
 Push the corresponding buttons to start the system in automatic mode.
 Observe the signal lamps (see Figure 5.2):
o Green -> Push the formwork to the next stop bolt
o Yellow -> Setting processes in the machine
o Red -> Machine is occupied
o Flashing red -> A fault occurred, observe error list.
 Put the frame formwork onto the inlet roller table.
 Push the frame formwork against the side stop.
 Push the frame formwork against the first stop bolt.
 The frame formwork is now measured. When this process has ended, the stop bolt re-
leases the formwork.
Generally, the corresponding personal protection must be
worn when working at the machine (safety shoes, safety
goggles, etc.).
Before switching on the machine, make certain that there
are no persons inside the machine or in its intake area.
Check that the machine is empty before starting automatic
mode. In particular after any service work, check that the
brushes are in their home positions.
