40 6 Maintenance and care
6.7 Lubrication points
Lubrication nipple A at the swivel shafts. 2 on either side of the machine.
Lubrication nipple B at the stop bolts.
Lubrication instructions
Power down the machine and secure it against reactivation.
Open safety doors.
Close doors after completing maintenance.
Perform test run.
Figure 6.5 Lubrication points swivel shafts and stop bolts
