Schwarz SB10B - 7.2 Transverse cleaning troubleshooting

7.2 Transverse cleaning 43
7.2 Transverse cleaning
Table 7.2 Transverse cleaning - measures at faults
No transverse cleaning
Error
Cause
Remedies
No power
- motor protection tripped
- check cause (E)
- control defective
- check (E)
- connections
- check (E)
- brush motor defective
- check (E)
Drive
- carriage bearing defective
- repair
- motor defective
- check motor (E)
- drive chain defective
- check, repair
- tappet screws defective
- replace
- control defective
- check (E)
- connections
- check (E)
- frequency converter
- check (E)
- PLC
- check (Schwarz GmbH)
Transverse
cleaning
sensors
- defective
- replace and readjust
- incorrect setting
- see "Setting up the transverse clean-
ing sensors"
Brush
- retention nut loose
- tighten
- tappet piece on shaft is miss-
ing
- check, insert if required
Transverse cleaning too strong or too weak
Error
Cause
Remedies
Transverse
cleaning
sensors
- sensor misadjusted
- see "Setting up the transverse clean-
ing sensors"
- defective
- check (E)
- PLC
- check (Schwarz GmbH)
- supply via screen
- correct
Drive
- PLC
- check (Schwarz GmbH)
- roller carriage bearing
- check, replace if required
- frequency converter
- check (E)
Brush
- worn
- replace
