Schwarz SB10B - Page 61

8.2 Total list mechanical spare and wear parts 61
Item no.017 002
Cylinder head screw for brush
shaft
M10x130
Transverse cleaning
Side cleaning
Item no.017 006
nut
for transverse cleaning and left
side cleaning
Right thread
Transverse cleaning
Side cleaning
Brush shaft
Item no.017 007
nut
for right side cleaning
Left thread
Side cleaning
Brush shaft
Item no.017 011
nut
Ø78x30
Cover cleaning
Height adjustment
Item no.018 001
Scraper plate left/right
150mm
Set = 6 pieces
Side cleaning
Item no.018 002
Cover scraper
Length = 1350
Set = 2 pieces
Cover cleaning
Scraper bar
Item no.018 056
Scraper box, right
Side cleaning
Right machine side
Item no.018 057
Scraper box left
Side cleaning
Left machine side
Item no.019 010
V-belt pulley
Ø125x13
Inner diameter = Ø20
Side cleaning
Supply
Item no.019 014
V-belt pulley
Ø63x13
Inner diameter = Ø17
Side cleaning
Supply
Item no.019 107
V-belt
DIN2215 size 13/560
Side cleaning
Supply
Item no.021 129
Safety disc
670x1090x4
Doors, sides
