Page 8 of 58
2.0 Packing List
If the outside of the shipping packaging is damaged, notify your shipping department immediately. The
shipping department may wish to notify the carrier at this point.
If the shipping carton is not damaged, carefully remove and identify all of the components as listed below. If
any of items are missing, contact Scientifica Ltd or your local distributor. Please retain the packaging for
storage or future transportation of the system.
2.1 Standard items
Above-
stage
variant
(fixed
objective)
One main optics module fitted with either
o One PMT module (rear position) and One
blanking plate (side position) or
o Two PMT modules.
One or Two signal cables (3.5 metres RG174
Coax, SMA to BNC with 50 –Ohm terminations).
One Support bracket (factory fitted)
Two M5 X 25 mm bolts for attaching to the
SliceScope
One Kit of Allen keys, including one 4 mm ball-
ended driver for the main attachment bolts.
Two transit caps (upper and lower)
One set of telescopic tubes (two pieces)
One U-MF2 Olympus filter cube (un-populated)
One 1U rack-mount two-channel controller unit
(without rack mounting screws)
One universal mains to 12V DC power supply,
low noise, with 2.5 mm DC barrel plug.
One user manual.
One mixed pollen grain slide (2P test target)
populated filter cube is provided, but it need not be used if only one
detection channel is required.
Dye-specific emission filters (purchased separately)
Miniature photo-multiplier tubes (PMT) together with an integrated high-
voltage power supply and an active voltage divider circuit which ensures
excellent linearity even for wide dynamic range targets under rapid scan
conditions.
Three PMT variants are offered (manufactured by Hamamatsu, Japan): a
blue/green sensitive R9880U-210 with very high efficiency in the blue to
offset poor transmission in some objective lenses, a red-sensitive R9880U-
01 and an extended-red-sensitivity R9880U-20. For bespoke
configurations (e.g. GaAsP PMTs) please contact Scientifica Ltd.
