Entry of a text
Title configuration
CDE AERO
Insert Copy Paste
Valid Delete title Delete a character Esc.
You move within the text using the “right” or “left” arrows on the keypad.
The characters are entered by means of the alphanumeric keys on the keypad.
Entering numerical values
The heading of the box provides information on the type of value entered, its unit and the variable concerned.
These indications are linked to the type of modified parameter.
Time in 1/10 second (6000)
0<= 0000 <=9999
Valid Esc.
Saves the changes and closes the dialogue box
Deletes the entire text
Deletes the letter shown by the cursor
Closes the menu without saving the changes
Name of the modified function
Text to be modified or created
Inserts a space to the left of the cursor
Saves the modifications and closes the screen
If it exists, indicates the lowest possible value
If it exists, indicates the highest possible value
Closes the screen without saving the modifications
