Section 02 MAINTENANCE
Subsection 01 (PERIODIC INSPECTION CHART)
DESCRIPTION
INTERVAL
I
: Inspect, verify, clean, adjust, lubricate.
Replace if necessary
C
:Clean
L
: Lubricate
R
: Replace
FIRST
10
HOURS
EVERY
25 HOURS
OR
3MONTHS
EVERY
50 HOURS
OR
6MONTHS
EVERY
100 HOURS
OR
1YEAR
LUBRICATION SYSTEM
Oil injection pump (5)
I I
Oil lines
I I
Oil filter
I I R
Oil reservoir straps
I
ELECTRICAL SYSTEM
Electrical connections and fastening (ignition system,
starting system, fuel injectors, etc.) (5)
I I
MPEM and ECU mounting support/fasteners
I
Digitally Encoded Security System and safety
lanyard/post
I I
Monitoring beeper I I
Battery support/fasteners I I
STEERING SYSTEM
Steering cable I I
Steering pole I I
Handlebar and adjuster operation I I
“Moto” seat I I
O.T.A.S.
tm
SYSTEM
O.T.A.S. system operation I I
PROPULSION SYSTEM
Drive shaft protection hose I(2)
Seal carrier L L
Driveshaft/impeller splines L
VTS (Variable Trim System)
I I
Jet pump reservoir oil R I R
Jet pump cover pusher I
Impeller shaft seal R(4)
Impeller and impeller/wear ring clearance I(2)
Water intake grate I(2)
2 smr2004-3D
