Section02MAINTENANCE
Subsection 04 (STORAGE)
STORAGE
ENGINE DRAINING
Disconnect the water supply hose used to cool
the magneto. It features a quick connect fitting.
Press both tabs and pull fitting in order to discon-
nect hose.
This hose is located at the bottom of the magneto
cover beside the engine support.
F22E02A
1
1. Press tabs here and disconnect hose
Water should flow out of the fitting (magneto cool-
ing circuit) and hose (crankcase heat exchanger).
Push and hold hose against bilge so that draining
can take place.
NOTE: It may be necessary to position the end of
thehoseinalowerareaofthebilgetoallowproper
drainage.
1
2
F17E0BA
1. Fitting
2. Hose
CAUTION: Water in heat exchanger system
must be free to flow out. Should water freeze
in engine, severe damage will occur.
Reconnect hose when done.
PROPULSION SYSTEM
Jet Pump
Lubricant in impeller shaft reservoir should be
drained. Reservoir should be cleaned and refilled
with SEA-DOO synthetic 75W90 GL5 polyester
oil. Refer to JET PUMP in the Shop Manual for
proper procedure.
CAUTION: Use only SEA-DOO jet pump oil or
equivalent synthetic gear oil, otherwise com-
ponent service life could be reduced. Do not
mix oil brands or types.
smr2004-3D 5
