Secutron MR-2320 Series User Manual

42
9.0 Configuration
Configure the MR-2320 Series Panels using the CFG-300 LCD Tool (see further
documentation packaged with CFG-300 for configuration information).
Table 8 Settings permitted in CAN/ULCS527
NOTICE TO USERS, INSTALLERS, AUTHORITIES HAVING JURISDICTION, AND OTHER INVOLVED PARTIES
This product incorporates field-programmable software. In order for the product to comply with the
requirements in CAN/ULCS527, Standard for Control Units for Fire Alarm Systems, certain programming
features or options must be limited to specific values or not used at all as indicated below.
Program feature or
option
Permitted in CAN/
ULCS527? (Y/N)
Possible settings\methods
Settings permitted in
CAN/ULCS527
Temporal pattern in
conjunction with manual
alarm evacuation
control
Y
Modes 1, 2, 3, 4, 5, 6, 7, 8, 9,
10, 11, 12, 13, 14
Modes 9, 11
Auto signal silence
timer
Y
Disabled or 5, 10, 20, or 30
minutes
All
Abort and manual
release on same circuit
(unsupervised)
N
Modes 1, 2, 3, 4, 5, 6, 7, 8, 9,
10, 11, 12, 13, 14
Modes 1, 2, 5, 6, 7, 8,
9, 10, 11, 12, 13, 14
Table 9 Settings permitted in UL864
NOTICE TO USERS, INSTALLERS, AUTHORITIES HAVING JURISDICTION, AND OTHER INVOLVED PARTIES
This product incorporates field-programmable software. In order for the product to comply with the
requirements in UL864, Standard for Control Units and Accessories for Fire Alarm Systems, certain
programming features or options must be limited to specific values or not used at all as indicated below.
Program feature or
option
Permitted in UL864?
(Y/N)
Possible settings\methods
Settings permitted in
UL864
AC power fail delay Y
0, 60, 180 minutes 60, 180 minutes
Temporal pattern in
conjunction with manual
alarm evacuation
control
Y
Modes 1, 2, 3, 4, 5, 6, 7, 8, 9,
10, 11, 12, 13, 14
Modes 9, 11
Auto signal silence
timer
N
Disabled or 5, 10, 20, or 30
minutes
Disabled
Abort and manual
release on same circuit
(unsupervised)
N
Modes 1, 2, 3, 4, 5, 6, 7, 8, 9,
10, 11, 12, 13, 14
Modes 1, 2, 5, 6, 7, 8,
9, 10, 11, 12, 13, 14
