6.0 Field Wiring
6.1 Main Board Field Wiring
Wire devices to the terminals as shown in the figures that follow. Refer to Wiring Tables and
Information on page 30 for wire gauges and Appendix C: Specifications on page 84 for
specifications.
Table 4 Settings permitted in CAN/ULCS527
NOTICE TO USERS, INSTALLERS, AUTHORITIES HAVING JURISDICTION, AND OTHER INVOLVED PARTIES
This product incorporates field-programmable software. In order for the product to comply with the
requirements in CAN/ULCS527, Standard for Control Units for Fire Alarm Systems, certain programming
features or options must be limited to specific values or not used at all as indicated below.
Program feature or
option
Permitted in CAN/
ULCS527? (Y/N)
Possible settings\methods
Settings permitted in
CAN/ULCS527
System Reset and
Signal Silence on MR-
2306-AT/MR-2312-AT
N
JW4 (Orange Wire) Intact =
Buzzer silence & Lamp Test
local function only. System
Reset & Signal Silence are
disabled.
Cut Jumper (Orange Wire) to
have all remote functions
operate.
Leave JW4 intact on
MR-2306-AT/MR-
2312-AT
Attention: Do not exceed power supply ratings.
To Next Page
