Pre-Programmed Modes
11.10 Mode 10: Agent Release, Single Hazard, Not Cross-zoned,
Combined Release
11.10.1 Zone Configuration
• Detection Zone -1: Alarm (Hazard Area1, not cross-zoned)
• Detection Zone -2: Alarm (Hazard Area1, not cross-zoned)
• Detection Zone -3: Alarm (Pressure Switch or Water-flow)
• Detection Zone -4: Supervisory
• Detection Zone -5: Abort Switch
• Detection Zone -6: Manual Release
• NAC -1: Signal, will be activated steady when there is any alarm zone active.
• NAC -2: Signal, indicate the Hazard Area1 status.
• RAC 1: Releasing Circuit
• RAC -2: Releasing Circuit
11.10.2 Hazard Configuration
• Default Release Timer Value: 60 seconds
• Default Manual Release Delay: 0 seconds.
• Default Abort Delay Type: Standard UL.
• Soak Timer Value: 0 seconds (continuous)
11.10.3 NAC Configuration
• Default Escalating NAC code of Hazard Area State:
• Hazard Idle: Off
• Hazard Alert: 20BPM
• Hazard Alarm: 60BPM
• Hazard Release: Steady
Detection Zones Phantom Zones Release Timers
Z1 Z2 Z3 Z4 Z5 Z6 Zp1 Zp2
RT1
Exp
RT2
Exp
Alm Alm WF Supv AB MR Z1+Z2 Z3+Z4
Out1 Signal Steady XXX X
Out2 Signal Escalating X(X) X X
Out3 Rel. Releasing XX
Out4 Rel. Releasing XX
RLS TMR 1 Started X
RLS Tmr 1 Interrupted X
RLS Tmr 1 Cancelled X
RLS Tmr 2 Started
RLS Tmr 2 Interrupted
RLS Tmr 2 Cancelled
