Secutron MR-2320 Series User Manual

70
Pre-Programmed Modes
11.9 Mode 9: Agent Release, Single Hazard, Cross-zoned, NYC
abort
11.9.1 Zone Configuration
• Detection Zone -1: Alarm (Hazard Area 1, cross-zoned)
• Detection Zone -2: Alarm (Hazard Area 1, cross-zoned)
• Detection Zone -3: Alarm (Pressure Switch or Water-flow)
• Detection Zone -4: Supervisory
• Detection Zone -5: Abort Switch
• Detection Zone -6: Manual Release
• NAC-1: Escalating Signal, indicate Hazard Area 1 status.
• NAC-2: Escalating Signal, indicate Hazard Area 1 status, Supervisory Optional.
• RAC-1: Releasing Circuit (Hazard Area 1)
• NAC-3: Silenceable Strobe.
11.9.2 Hazard Configuration
• Default Release Timer Value: 60 seconds
• Default Manual Release Delay: 0 seconds
• Default Abort Delay Type: NYC
• Default Soak Timer Value: 0 seconds (continuous)
11.9.3 NAC Configuration
• Default Escalating NAC code of Hazard Area State:
• Hazard Idle: Off
• Hazard Alert: Steady
• Hazard Alarm: 120BPM
• Hazard Release: Steady
Detection Zones Phantom Zones Release Timers
Z1 Z2 Z3 Z4 Z5 Z6 Zp1 Zp2
RT1
Exp
RT2
Exp
Alm Alm WF Supv AB MR Z1+Z2 Z3+Z4
Out1 Signal Steady X
Out2 Signal Escalating X(X) X X
Out3 Rel. Releasing XX
Out4 Strobe Steady XXX X
RLS TMR 1 Started X
RLS Tmr 1 Interrupted X
RLS Tmr 1 Cancelled X
RLS Tmr 2 Started
RLS Tmr 2 Interrupted
RLS Tmr 2 Cancelled
