9.2 Entering the Passcode
The programming section is passcode protected. The following screen shows the message
that is displayed to enter the passcode. The maximum allowable passcode is ten digits long,
and permits numerical values only. Press (Enter button) after entering the passcode. If
the passcode is correct, it will take you to the main command menu. If the passcode is wrong
the system will ask you to re-enter passcode. The system will be exhausted after three retries
and will then take you back to the Normal message display.
Three levels of access are defined in Table 10:
When the user presses “MENU” and enters the password, they should enter the password of
the level intended. If the user is in a lower level of access, attempts to operate functions
requiring a higher level of access will be refused.
9.3 How to Use the Keypad to Program the MR-2320
1. Press (Menu button). You will be prompted to enter your password.
2. Enter your password, then press (Enter button) to continue.
3. Select a Command Menu option by pressing . The corresponding submenu will display.
4. Use the up and down arrow buttons to scroll through the submenu.
5. Press to select a submenu option.
6. Use the left or right arrow buttons to select/unselect an option (selected = “X
”). Use the up and
down arrows to scroll through the different menu options. When entering numerical data, use
the up and down arrows to increase or decrease the number.
7. Once you have made the correct selection, press to confirm the change. The display will
return to the submenu screen.
8. Press (Cancel button) to return to the previous menu.
Table 10 Access Levels
Access Level Description
Level 0 - Command The default password is for this level “1111” without quotes. In this level the
user can only perform regular testing and operation.
Level 1 - Configuration The default password is for this level “2222” without quotes. User can
change configuration and have access to command level.
Level 2 - Factory Currently not used.
