5.2 Content of a Fault Record

A fault record comprises information about:

Part 1: Common Information (independent of protection function)

Runtime (Startup No.) Timestamp of the Fault. This speci󰊟es the uptime of the WIC1, and the

total number of WIC1 restarts (in parentheses).

Example: 1d 01:14:23.848 (4) — The fault occurred at 1 day, 1 hour,

14 minutes, 23.848 seconds after the 4

restart. (Restarts counted from

WIC1 delivery.)

Fault No. This counter will be incremented with each fault (i. e. with every

(General) Pickup »Prot . Pickup«).

Time to trip The time between pickup and trip. Please note: No time to trip will

be shown if the 󰊟rst pickup and the 󰊟rst trip are issued by di󰊞erent

protection stages or modules.

Pickup Name of the module / protection stage that picked up 󰊟rst.

Trip Name of the module / protection stage that tripped 󰊟rst.

Part 2: Information depending on the active settings

Measured Values Various measuring values at the time of the pickup or trip are displayed.

181WIC1WIC1-1.0-EN-MAN

5 Fault Recorder

5.2 Content of a Fault Record
