3.1.1
Terminals, Screws and Torques
CAUTION!
Be careful. Do not overtighten the mountings nuts of the relay. Check the torque by
means of a torque wrench with respect to the max. torque values in the table. Over-
tightening the mounting nuts could cause personal injury or damage the relay.
Slot Tightening
Torques of
the Screws
Screw Type Description
PE 1.6 Nm
(14.2 lb⋅in)
nut, 7 mm Screw-type connector for Protective Earth. See ╚═▷ “3.3.1 Grounding”.
X0 0.5 Nm
(4.4 lb⋅in)
M3 slotted Measuring input for ground (earth) current (for some order options) — See
╚═▷ “3.4 Phase and Ground Current Measuring Inputs”.
X1, X2,
X3
Inputs for
WIC1 CTs:
0.5 Nm
(4.4 lb⋅in)
Inputs for
Broad-
Range CTs:
0.22 Nm
(1.9 lb⋅in)
Inputs for
WIC1 CTs:
M3 slotted
Inputs for
Broad-
Range CTs:
M2 slotted
Measuring inputs for phase currents — See ╚═▷ “3.4 Phase and Ground
Current Measuring Inputs”.
X4 0.5 Nm
(4.4 lb⋅in)
M3 slotted Pin assignments depending on the order option, for example:
Impulse signal outputs for a trip coil and for a 󰊠ag indicator — See ╚═▷
“3.7 Outputs (Trip Coil, Flag Indicator, Relay Output)”.
Only some variants of WIC1‑1… / WIC1‑2… / WIC1‑3…: Input e. g. for
an external trip signal — See ╚═▷ “3.5 Digital Input (only WIC1‑1… /
WIC1‑2… / WIC1‑3…)”
Only WIC1‑4…: Digital Inputs incl. additional auxiliary power supply —
See ╚═▷ “3.6 Additional Power Supply and Digital Inputs (WIC1‑4…
only)”
X5 RJ45 connection to the DiggiMEC.
Ethernet CAT3 cable or better, but beware, this is not an Ethernet
connection! Beware, crossover cables must not be used!
See also ╚═▷ “2.7 Settings – Operation.
X6 0.22 Nm
(1.9 lb⋅in),
except:
two screws
for 󰊟xing the
connector:
0.3 Nm
(2.6 lb⋅in)
M3 slotted,
except:
two screws
for 󰊟xing the
connector:
M2 slotted
Only some variants of WIC1‑4:
RS485 connector for SCADA communication. Note that SCADA will
become available with a later release.
X7 Only some variants of WIC1‑4:
RJ45 or 󰊟ber optics connector for Ethernet-based SCADA communication.
Note that SCADA will become available with a later release.
0.6 Nm
(5.3 lb⋅in)
M3 crosshead Plastic cover for protecting and covering the lateral terminals, fastened with
one non-losable screw.
0.6 Nm
(5.3 lb⋅in)
M3 crosshead Only for variants of WIC1‑2, WIC1‑3:
56 WIC1 WIC1-1.0-EN-MAN
3 Hardware
3.1.1 Terminals, Screws and Torques
