Seg WIC1 User Manual

2.6.1.2 Order Form of the Dual-Powered WIC1‑4
Dual-Powered Time Overcurrent and Earth
Current Relay
WIC1 ‑ # # # # # # # # #
Mounting form ↓
Dual-Powered Powered Relay, parameter setting via
DiggiMEC
4
CT Type ↓
WIC1 CTs S
Broad-Range CTs
(##)
B
Earth current protection ↓
With ground (earth) current measuring inputs, rated ground/earth
current: 1 A
(**4)
G
Nominal frequency ↓
50 Hz / 60 Hz
(***4)
0
Outputs ↓
The Trip Command is assigned to the “TC” (Trip Coil pulse) output. (This assignment
is pre-de󰊟ned and 󰊟xed.)
N
The Trip Command is assigned to both the “TC” (Trip Coil pulse) output and to the
“FI” (Flag Indicator) output.
F
The Trip Command is 󰊟xed and assigned to the “TC” (Trip Coil pulse) output. The
“Out” output can be con󰊟gured.
C
Inputs ↓
No digital inputs M
External trip input, external reset input G
2 assignable Digital Inputs D
Backup protection ↓
Backup protection operates directly
(****)
1
Trip at 20⋅In,max 2
Protection Packages ↓
ANSI 50, 50G/N, 51, 51G/N, Inrush Blocking, 50BF, 62BF, 74TC S
ANSI 50, 50G/N, 51, 51G/N, Inrush Blocking, 46, 51Q, 49, 50BF, 62BF, 74TC A
ANSI 50, 50G/N, 51, 51G/N, Inrush Blocking, 46, 51Q, 49, 50BF, 62BF, 74TC, SOTF, ultra-fast overcurrent
protection
P
Communication
(#)
↓
Without communication protocol
(#)
A
