Seg WIC1 User Manual

11.1.3.2 DIP-/HEX-Switch Settings for CT Type W3
CT Type W3
Primary Rated CT
Current In in
Ampere
Relative Rated
Current
»In,relative«
in In
,min
(Prim. Rated
Current for WIC1-
W3 = 32 ⋅ Relative
Rated Current)
HEX 1 DIP 1-1 DIP 1-2 DIP 1-3 DIP 1-4
32 1.0 0 OFF OFF OFF OFF
36 1.125 1 ON OFF OFF OFF
40 1.25 2 OFF ON OFF OFF
44 1.375 3 ON ON OFF OFF
48 1.5 4 OFF OFF ON OFF
52 1.625 5 ON OFF ON OFF
56 1.75 6 OFF ON ON OFF
60 1.875 7 ON ON ON OFF
64 2.0 8 OFF OFF OFF ON
68 2.125 9 ON OFF OFF ON
72 2.25 A OFF ON OFF ON
80 2.5 B ON ON OFF ON
88 2.75 C OFF OFF ON ON
96 3.0 D ON OFF ON ON
104 3.25 E OFF ON ON ON
112 3.5 F ON ON ON ON
256 WIC1 WIC1-1.0-EN-MAN
11 Appendix
11.1.3.2 DIP-/HEX-Switch Settings for CT Type W3
