Seg WIC1 User Manual

11.1.3.3 DIP-/HEX-Switch Settings for CT Type W4
CT Type W4
Primary Rated CT
Current In in
Ampere
Relative Rated
Current
»In,relative«
in In
,min
(Prim. Rated
Current for WIC1-
W4 = 64 ⋅ Relative
Rated Current)
HEX 1 DIP 1-1 DIP 1-2 DIP 1-3 DIP 1-4
64 1.0 0 OFF OFF OFF OFF
72 1.125 1 ON OFF OFF OFF
80 1.25 2 OFF ON OFF OFF
88 1.375 3 ON ON OFF OFF
96 1.5 4 OFF OFF ON OFF
104 1.625 5 ON OFF ON OFF
112 1.75 6 OFF ON ON OFF
120 1.875 7 ON ON ON OFF
128 2.0 8 OFF OFF OFF ON
136 2.125 9 ON OFF OFF ON
144 2.25 A OFF ON OFF ON
160 2.5 B ON ON OFF ON
176 2.75 C OFF OFF ON ON
192 3.0 D ON OFF ON ON
208 3.25 E OFF ON ON ON
224 3.5 F ON ON ON ON
