11.1.3.5 DIP-/HEX-Switch Settings for CT Type W6
CT Type W6
Primary Rated CT
Current In in
Ampere
Relative Rated
Current
»In,relative«
in In
,min
(Prim. Rated
Current for WIC1-
W6 = 256 ⋅ Relative
Rated Current)
HEX 1 DIP 1-1 DIP 1-2 DIP 1-3 DIP 1-4
256 1.0 0 OFF OFF OFF OFF
288 1.125 1 ON OFF OFF OFF
320 1.25 2 OFF ON OFF OFF
352 1.375 3 ON ON OFF OFF
384 1.5 4 OFF OFF ON OFF
416 1.625 5 ON OFF ON OFF
448 1.75 6 OFF ON ON OFF
480 1.875 7 ON ON ON OFF
512 2.0 8 OFF OFF OFF ON
544 2.125 9 ON OFF OFF ON
576 2.25 A OFF ON OFF ON
640 2.5 B ON ON OFF ON
704 2.75 C OFF OFF ON ON
768 3.0 D ON OFF ON ON
832 3.25 E OFF ON ON ON
896 3.5 F ON ON ON ON
259WIC1WIC1-1.0-EN-MAN
11 Appendix
11.1.3.5 DIP-/HEX-Switch Settings for CT Type W6
