Door cutout (Height / Width): 45 mm / 92 mm
Material, Housing: Plastic
Weight:
• DiggiMEC‑A (without packaging): approx. 160 g•
• DiggiMEC‑A (incl. packaging): approx. 300 g•
• DiggiMEC‑B (without packaging): approx. 190 g•
• DiggiMEC‑B (incl. packaging): approx. 330 g•
9.3.3
Degree of Protection EN 60529
Front panel with seal IP52
Front panel without seal IP50
Rear side terminals IP20
9.3.4
Voltage Supply
Supply via WIC1 CTs
With the setting »Preference for Operation« = “Early wake-up”:
•
1-phase wakeup = 0.6 In
,min
•
•
3-phases wakeup = 0.4 In
,min
•
With the setting »Preference for Operation« = “Precise meas.”:
• 1-phase wakeup = 1.1 In
,min
•
•
3-phases wakeup = 0.75 In
,min
•
Since the setting »Preference for Operation« = “Early wake-up” results in less
accurate measurement values it is recommended in general to keep the default value
“Precise meas.”.
