Seg WIC1 User Manual

9.6 Technical Data – WI1SZ5
Coil voltage: 24 V DC ± 10%
Contact Rating:
• 230 V AC / 3 A•
• 230 V DC / 0.12 A•
• 115 V DC / 0.2 A•
•
24 V DC / 2 A
•
• The WI1SZ5 has two potential-free changeover contacts.•
• The WI1SZ5 can be set and reset electrically.•
The WI1SZ5 can be reset mechanically.
Cable Color Diameter Function
Coil connection brown 0.25mm² (−) Ground
violet 0.25mm² (+) Set
orange 0.25mm² (+) Reset
Changeover contact 1 black 0.5mm² NO contact
blue 0.5mm² changeover contact
red 0.5mm² NC contact
Changeover contact 2 white 0.5mm² NO contact
yellow 0.5mm² changeover contact
green 0.5mm² NC contact
“NO”: normally open. “NC”: normally closed.
Maximum cable connection length: 1 m
