Setting of the Tripping Delay or »tChar« Factor of the Phase Overcurrent
Protection Stage I>
WIC1‑2: DIP switch block 2, switches 5…8
WIC1‑3: HEX switch 4
If “DEFT” is set as the characteristic (╚═▷ “Setting of the Characteristic of Phase Overcurrent
Protection Stage I>”) this is the setting for the tripping delay in seconds.
If any of the inverse characteristics is set (╚═▷ “Setting of the Characteristic of
Phase Overcurrent Protection Stage I>”) this is the »tChar« factor of the inverse-
time characteristic.
Tripping Delay
»I> . t«
in seconds
Characteristic
Factor
»I> . tChar«
HEX 4 DIP 2-5 DIP 2-6 DIP 2-7 DIP 2-8
0.04 0.05 0 OFF OFF OFF OFF
0.3 0.1 1 ON OFF OFF OFF
0.6 0.2 2 OFF ON OFF OFF
1.0 0.3 3 ON ON OFF OFF
2.0 0.4 4 OFF OFF ON OFF
3.0 0.5 5 ON OFF ON OFF
4.0 0.6 6 OFF ON ON OFF
6.0 0.8 7 ON ON ON OFF
8.0 1 8 OFF OFF OFF ON
10.0 2 9 ON OFF OFF ON
15.0 3 A OFF ON OFF ON
30.0 4 B ON ON OFF ON
60.0 5 C OFF OFF ON ON
120.0 6 D ON OFF ON ON
210.0 8 E OFF ON ON ON
300.0 10 F ON ON ON ON
262 WIC1 WIC1-1.0-EN-MAN
11 Appendix
11.1.4 Phase Overcurrent Protection – Settings via DIP Switches (WIC1‑2) or via HEX Switches (WIC1‑3)
