④ RotatethegearsothattheD-cutside
oftheVRaxleishorizontaland
facingdownward.
⑤InserttheVRunitwithoutcausingthe
geartorotateandsecureitwith2
screws.Thegearengagementshould
alsobeadjustedatthistime.
⑥ Checktomakesurethe"SEAT
MOTION"valueontheInputTest
screeniswithintherange80H ± 8H
whentheseatislevel.Ifthevalueis
outsidethisrange,adjusttheVR
again.
DCUTSIDE
Horizontaland
facingdownward
PHOTO12.2b
① Turnoffthepower.
② Removethe6trussscrewsholdingthefrontlidofthebaseinplaceandthenremovethelid.
③RemovetherollVRunit.Unplugtheconnectorsandremovethe2screwsholdingtherollVR
bracketinplace.
ROLLVRUNIT
CONNECTOR
PHOTO12.2c
REPLACEMENTPROCEDURE
SCREW(2)
M4×8,w/flat&springwashers
