Impulse 300D – User Manual
Page 14 (67)
2.1 Rack Installation
The IMPULSE 300D unit can be easily deployed almost anyplace. The size is small
enough that the unit can be placed on a desk, in an equipment rack or on a shelf at a
test bench.
2.2 Power Connection
Using the proper power connections is vital to the safe operation of the IMPULSE
300D. Only use the supplied 3-prong power connector or one with equal specifications.
NEVER tamper with or remove the 3
rd
– prong grounding pin. This could cause
damage to the IMPULSE 300D, personnel, or property.
2.3 AC Power Connection
The IMPULSE 300D is intended for use on either 120V or 240V systems. The power
supply will automatically detect the system it is connected to. To hook up the power
use the following steps:
1. Locate the AC power cord that was included with the IMPULSE 300D.
2. Plug the female end of the power cord (end with no prongs) into the back of the
unit.
3. Locate a protected outlet (usually inside of the rack) to plug the male end of the
power cable into.
2.4 Maintenance
The IMPULSE 300D is virtually a maintenance-free piece of equipment. There are no
user serviceable parts on the inside of the unit.
