55
Trigon-6 Operation Manual
Aftertouch
Pitch Wheel
You can set a range in semitones for the Pitch wheel, depending on your
playing preference. The range is up to 12 semitones (1 octave). Many
musicians use a range of 2 semitones (a whole step) since this is the bend
range of many acoustic instruments. For guitar whammy bar effects, you
many wish to set a wider range.
To set the pitch bend range:
1. In the Miscellaneous Parameters section, press and hold the p whl
range button.
2. With the button still held down, use the bank/decrement and tens/
increment switches to choose the number of semitones (up to 12) for
the pitch bend range, then release the p whl range button.
Modulation Wheel
The Mod wheel controls the amount of modulation applied to any destina-
tions chosen in the lfo section. This allows you to “perform” LFO modu-
lation in real time by moving the Mod wheel. This is a great way to add
expressiveness to a sound or performance.
To choose a modulation destination for the Mod wheel:
1. In the lfo section, choose a modulation destination as well as a shape
and frequency for the LFO. (See “” on page 31 for more details.)
2. To apply modulation only when using the Mod wheel, set the initial
amt knob to zero. (Turing this knob up will apply LFO modulation
continuously — not just when the Mod wheel is used.)
Many programs use the Mod wheel to add vibrato. In this case, Freq 1 and
Freq 2 are enabled as modulation destinations in the low-frequency oscillator
section. This adds vibrato when you push the mod wheel forward. Set the initial amt
knob to zero to apply vibrato only when using the Mod wheel.
Aftertouch
