4.3 Lock Override
lf you need to replace a broken or lost scanner that is linked to a cradle, scan the Lock Override code
below with a new scanner and place that scanner in the cradle, or scan the Pairing Barcode. The locked
link will be overridden; the broken or lost scanner's link with the cradle will be removed,and the new
scanner will be linked.
Lock Override
4.4 Pairing
Pairing registers a wireless scanner to the cradle such that the wireless scanner and cradle can
exchange information. The cradle operates in two modes: Point-to-Point and Multipoint-to-Point.
In Point-to-Point mode，you can pair a wireless scanner to the cradle in the following three ways:
A:Scan the pairing barcode，but the following two conditions must be met at the same time:
a:Neither the wireless scanner nor the cradle has pairing information
b:The Bluetooth pairing mode of the wireless scanner and the cradle are the same(both
Point-to-Point mode or both Multipoint-to-Point)
B:Insert the wireless scanner in the cradle, but the following condition must be met:
a:Neither the wireless scanner nor the cradle has pairing information
C:Scan the “Override” barcode, and Insert the wireless scanner in the cradle:
a:Unconditional connection, the cradle Bluetooth pairing mode (Point-to-point/Multipoint-to-point)
will also be set to be consistent with the wireless scanner
In Multipoint-to-point mode，you can pair the wireless scanners to the cradle in the following steps：
a:Scan Lock Override code in 4.3;
b:Scan Multipoint-to-Point code in 4.2;
c:Place the scanner in the cradle, or scan the Pairing Barcode;
d:Follow the steps a to c above to pair other scanners in turn
Note:Multipoint-to-Point communication mode allows up to four scanners to pair to one cradle
4.5 Connect/disconnect indication
A high beep followed by the blue LED of the cradle flashes once, and the blue LED of the wireless
scanner stays on for 10 seconds indicates successful pairing. A high-high beep sequence indicates
disconnection to cradle.
