Startup
Control elements
Operating Instructions – MOVIMOT
®
flexible
141
6.4.4 Potentiometer t1
Use the potentiometer t1 to set the acceleration/deceleration setpoint t1.
• When the device is set to Easy mode, the predefined setpoint is always active at
the potentiometer t1.
• The potentiometer t1 can be deactivated in Expert mode.
In this case, the parameters Acceleration 1 and Deceleration 1 of the fixed setpoint
processing are activated.
3
4
5
6
7
8
The following table lists the scaling of acceleration/deceleration setpoint t1 depending
on the setting of potentiometer t1:
Potentiometer t1
Detent setting 0 1 2 3 4 5 6 7 8 9 10
Acceleration/decel-
eration
min
-1
s
-1
30000 15000 10000 6000 4286 3000 1500 1000 600 429 300
Ramp time
1)
s
0.1 0.2 0.3 0.5 0.7 1 2 3 5 7 10
1) Alternative information on the equivalent ramp times for acceleration/deceleration based on a speed change of 3000min-1.
