6
Startup
DIP switch
Operating Instructions – MOVIMOT
®
flexible
147
DIP switch S3/3 – S3/4: Motor assignment
Use these DIP switches to select the relative motor power in relation to inverter power.
The selection depends on the selected motor series, motor connection type, and the
nominal output current of the electronics cover.
S3/3 S3/4 Motor assignment
0 0 Adjusted
1 0 1 stage smaller
0 1 2 stages smaller
1 1 3 stages smaller
DIP switch S3/5 – S3/6: Motor protection
Use these DIP switches to select the temperature sensor type for thermal protection of
the motor.
S3/5 S3/6 Motor protection
Temperature sensor type
0 0 No temperature sensor
1)
1 0 PK (PT1000)
0 1 TF
1 1 TH
1) If no temperature sensor is selected, basic temperature protection of the motor is realized via the firm-
ware function of the inverter.
29129451/EN – 12/2019
