Startup
DIP switch
Operating Instructions – MOVIMOT
®
flexible
148
DIP switch S3/7 – S3/10: Motor series
Use these DIP switches to select the motor series (motor type).
Code S3/7 S3/8 S3/9 S3/10 Motor series
Motor type Nominal voltage
Nominal frequency
1 0 0 0 0 DRN..
4-pole
230V/400V
50Hz
2 1 0 0 0 DRN..
4-pole
266V/460V
60Hz
3 0 1 0 0 DRN..
4-pole
Wide-range voltage
50/60Hz
4 1 1 0 0 DR2S..
4-pole
230V/400V
50Hz
5 0 0 1 0 DR2S..
4-pole
266V/460V
60Hz
6 1 0 1 0 DR2S..
4-pole
Wide-range voltage
50/60Hz
7 0 1 1 0
MOVIGEAR
®
classic
400V
–
8 1 1 1 0 Reserved –
9 0 0 0 1 Reserved –
10 1 0 0 1 Reserved –
11 0 1 0 1 Reserved –
12 1 1 0 1 Reserved –
13 0 0 1 1 Reserved –
14 1 0 1 1 Reserved –
15 0 1 1 1 Reserved –
16 1 1 1 1 Reserved –
Nominal voltage range for wide-range voltage motors
50Hz 60Hz
m W m W
220 – 240V 380 – 420V 254 – 277V 440 – 480V
29129451/EN – 12/2019
