SEW-Eurodrive MOVIMOT flexible MMF1 C/DBC Series - Configuration 0: User-defined configuration

7
Operation
Binary control
Operating Instructions – MOVIMOT
®
flexible
170
7.2.1 Configuration 0: User-defined configuration
Function of the di-
gital inputs
• The digital inputs can be configured freely.
• In contrast to the predefined terminal configurations 1–6, the drive unit remains in
the status "FCB02 Stop default" once the enable signal is revoked. If you require
the status "FCB01 Output stage inhibit", you must assign this function to a digital
input.
Configuring the
fixed setpoint pro-
cessing modes
• The fixed setpoint processing modes can be configured freely.
Fixed setpoint
processing mode
Functions of the setpoint sources
• Unipolar fixed setpoint
• Bipolar fixed setpoint
• Fixed setpoint + analog setpoint
• Fixed setpoint × analog setpoint
No function:
• Potentiometer f1
• Potentiometer f2
• DIP switch S2/2
Scaling of analog input AI1:
• Scale the speed setpoint by setting the
scaling factor of analog input AI1
• Primary frequency
• Motor potentiometer
No function:
• Potentiometer f1
• Potentiometer f2
• DIP switch S2/2
Function of analog input AI1:
• You cannot use analog input AI1 for the
speed setpoint.
Scaling of analog input AI1:
• Scale the speed setpoint by setting the
scaling factor of analog input AI1
• Mechanical setting elements
No function:
• Scale the speed setpoint using the scaling
parameter of analog input AI1
Scaling of analog input AI1:
• Set permanently to 0–100% of parameter
Application limit – positive/negative speed
setpoint
