SEW-Eurodrive MOVIMOT flexible MMF1 C/DBC Series User Manual

7
Operation
Binary control
Operating Instructions – MOVIMOT
®
flexible
172
7.2.3 Configuration 2: Enable, fixed setpoints
Fixed setpoint processing mode: Mechanical setting elements
(cannot be changed)
Behavior of the drive unit Digital input "DRIVE"
LED
DI01 DI02 DI03 DI04
Enable Fixed
setpoint
2
0
Fixed
setpoint
2
1
Reset
The drive unit stops with deceleration setpoint t1.
1)
FCB01 Output stage inhibit is activated afterwards.
0 x x x Lights up
yellow
The drive unit is running with the fixed speed setpoint1.
The direction of rotation is specified by the sign of the
fixed setpoint.
The acceleration setpoint t1 is active.
1)
1 1 0 x Illuminated
in green
The drive unit is running with the fixed speed setpoint2.
The direction of rotation is specified by the sign of the
fixed setpoint.
The acceleration setpoint t1 is active.
1)
1 0 1 x Illuminated
in green
The drive unit is running with the fixed speed setpoint3.
The direction of rotation is specified by the sign of the
fixed setpoint.
The acceleration setpoint t1 is active.
1)
1 1 1 x Illuminated
in green
The drive unit is running in positive direction of rotation
(clockwise rotation) with the analog speed setpointf1.
2)
The acceleration setpoint t1 is active.
1)
1 0 0 x Illuminated
in green
The drive unit is in fault state. x x x x Lights up
or flashes
red
The fault state has been reset. 0 0 0 1 Lights up
yellow
1) If potentiometer t1 is deactivated using the parameter settings, the acceleration setpoint 1/ deceleration setpoint 1 of the fixed set-
point processing will be activated.
2) If DIP switch S2/2 (Analog setpoint selection) is set to "ON", the speed setpoint of analog input AI1 is used instead of speed setpoint
f1.
0 = No voltage 1 = 24V x = Any
29129451/EN – 12/2019
