Operation
Binary control
Operating Instructions – MOVIMOT
®
flexible
176
7.2.7 Configuration 6: CW, CCW, primary frequency
Fixed setpoint processing mode: Primary frequency setpoint
(cannot be changed)
Behavior of the drive unit Digital input "DRIVE"
LED
DI01 DI02 DI03 DI04
Right Left Input
fre-
quency
Reset
The drive unit stops with deceleration setpoint t1.
1)
FCB01 Output stage inhibit is activated afterwards.
0 0 x x Lights up
yellow
The drive unit is running in positive direction of rotation
(clockwise rotation) with the speed setpoint defined in
the primary frequency function.
The acceleration setpoint t1 is active.
1)
1 0 0–
120kHz
x Illuminated
in green
The drive unit is running in negative direction of rotation
(counterclockwise rotation) with the speed setpoint
defined in the primary frequency function.
The acceleration setpoint t1 is active.
1)
0 1 0–
120kHz
x Illuminated
in green
The drive unit stops with deceleration setpoint t1.
1)
After that, FCB02 Stop default is activated.
1 1 x x Flashing
green
The drive unit is in fault state. x x x x Lights up
or flashes
red
The fault state has been reset. 0 0 0 1 Lights up
yellow
1) If potentiometer t1 is deactivated using the parameter settings, the acceleration setpoint 1/ deceleration setpoint 1 of the fixed set-
point processing will be activated.
0 = No voltage 1 = 24V x = Any
29129451/EN – 12/2019
