Technical data and dimension sheets
Technical data
Operating Instructions – MOVIMOT
®
flexible
309
11.3.4 Current carrying capacity of terminals
Current carrying capacity of terminals
Line terminals X1 24A (max. loop-through current)
Control terminals X9 10A (max. loop-through current)
11.3.5 DC24V supply
Input for the independent backup voltage supply of the electronics
DC24V input 24V_IN U
IN
= DC24V -10%/+20% according to EN61131-2
Current consumption:
I
E
≤500mA, typically 100mA for electronics
• Plus up to 100mA, for sensor supply
0V24_IN
11.3.6 DC24V output
Internal voltage supply for the sensors
DC24V output
X9
24V_OUT U
OUT
= DC24V -10%/+20% according to EN61131-2
External-voltage-proof and short-circuit proof
Permitted output current: I
OUT
≤ 100mA
0V24_OUT
11.3.7 Digital inputs
Digital inputs
Number of inputs 4
Input type PLC-compatible according to EN61131-2 (digital inputs type 3)
DI01 – DI04: R
i
≈4.5kΩ, sampling cycle ≤2ms
Signal level
DC +11 to +30 V = "1" = Contact closed
DC -3 to +5 V = "0" = Contact open
Sensor/actuator supply DC24V to EN61131-2,
External-voltage-proof and short-circuit proof
Maximum line length 30m
Permitted total current for
internal supply
100mA (total of all connected sensors/actuators, maximum individual load:
100mA)
Permitted total current for
external supply
100mA (total of all connected sensors/actuators, maximum individual load:
100mA)
