11
Technical data and dimension sheets
Technical data
Operating Instructions – MOVIMOT
®
flexible
311
11.3.10 Electronics data – Drive safety functions
The table below shows the technical data for the drive unit relating to the integrated
safety technology.
The safe digital inputs comply with type 3 according to IEC61131‑2.
Reference potential for the F_STO_P1 and F_STO_P2 is F_STO_M (contact at termi-
nal X9:11).
Terminal desig-
nation
General electronics data
Safety contact STO X9
Electrical data of inputs F_STO_P1,
F_STO_P2
Minimum Typical Maximum
Input voltage range X9:1 and X9:21 DC-3V DC24V DC30V
Input capacitance against STO_M – 300pF 500pF
Input capacitance against GND – 300pF 500pF
Power consumption at DC24V F_STO_P1 – 150mW 200mW
F_STO_P2 – 150mW 200mW
Sum
1)
– 300mW 400mW
Input voltage for ON status (STO) DC11V – –
Input voltage for OFF status (STO) – – DC5V
Permitted leakage current of the external safety
controller
– – 1mA
Technical data
Time from disconnecting the safety voltage until
deactivation of the rotating field
– 1.5ms 10ms
2ms
2)
Time from connecting the safety voltage until acti-
vation of the rotating field
– – 110ms
1) Each drive unit always requires a power consumption of 300mW.
2) Only when a safety card by SEW‑EURODRIVE is used
29129451/EN – 12/2019
